Truck-mounted Aerial Platform FORSTE 23t SPEED
MAX. WORKING HEIGHT
ROTATION RANGE
SUPPORTS
PLATFORM HEIGHT
BASKET SIZE
CONTROL
MAX. LATERAL REACH
BASKET LOAD
BASKET ROTATION
TOTAL WEIGHT
Truck-mounted aerial platform | High Reach
High Performance
Multi-zone Stabilization
Positioning on uneven ground
Automatic stabilization
The FORSTE 23T SPEED truck-mounted aerial platform is a powerful telescopic truck-mounted aerial platform, equipped as standard with automatic outriggers, with an optimal total truck weight of 3.5 t, capable of reaching a working height of 22.80 m and a large lateral outreach of 12.50 m with a capacity of 230 kg (2 operators + material).
The Socage SPEED HE+H function increases safety and facilitates correct outrigger deployment maneuvers. It is equipped as standard with SOCAGE’s automatic HE+H outrigger system, featuring vertical outriggers and automatic return to the transport position (HOME function). Additionally, it enables outrigger deployment from the basket as a standard feature.
SPEED HE+H is a very versatile and easy-to-use automatic outrigger system that enables high performance in a safe and reliable manner. The multi-zone stabilization with multiple working areas allows for various outrigger configurations to optimally utilize space in every situation. The front outriggers can be hydraulically extended to increase the stabilization area.
Improved ability to compensate for height differences
The additional stroke of the SOCAGE vertical outriggers enables better compensation for height differences and protects the support surface.
The construction of the booms from advanced, high-strength steel profiles (SPP), in conjunction with the innovative SOCAGE design of the chassis and superstructure, ensures a lightweight aerial work platform with a robust structure and excellent performance.
The new hydraulic system, in conjunction with the Socage control console, enables smoother movements and greater control for the operator, even during multiple simultaneous movements.
The excellent lateral outreach and the high working height allow for a wide working envelope, which, together with the automatic SPEED outrigger function, is also valued by rental companies who wish to offer their customers well-designed aerial platforms with above-average performance.
STANDARD EQUIPMENT
AUTOMATIC STABILIZATION
With just one push of a button, even from the platform, you can work safely, easily, and quickly after release.
The additional lifting reserve of the Socage vertical stabilizers perfectly complements the SPEED automatic stabilization, ensuring safe stabilization with an increased ability to overcome irregularities.
TECHNICAL FEATURES
Internal hose and cable routing in the boom arm.
Automatic Home function.Automatic SPEED outrigger system with variable HE+H stabilization.Vertical outriggers with extended stroke.Outrigger control from basket and ground control station.Electro-hydraulic proportional control for all movements.Electronic CAN BUS control.4 outrigger pads.230V and 12V socket in the work basket.Simultaneous control possible.Cataphoresis treatment with powder coating.Centering indicator light in the work basket.Automatic speed regulation.
SAFETY DEVICES
Socage safety system against unintentional control movements.
Protective strip against unintentional actuation.
Cover basket control.
Magnetothermal FI circuit breaker on 230V line.
Safety bypass for the recovery of the operator.
Automatic leveling.
Load moment limiter with double safety.
Automatic basket leveling.
Inclinometer.
Flanged block valves.
Emergency stop switch.
Manual emergency pump.
Remote-controlled emergency operation possible.
Automatic shutdown PTO.
Anti-collision protection boom/vehicle cab.
Digital hour meter in the driver’s cab.
Support control light in vehicle cab.
Maintenance indicator (service).
Safety lighting on the aerial work platform
PERSONALIZE YOUR AERIAL PLATFORM
More than 40 years of experience
